| 1. AC input |
| 2. USB port |
| 3. Update port |
| 4. Balance port for channel 1 |
| 5. Battery port for channel 1 |
| 6. Battery port for channel 2 |
| 7. Balance port for channel 2 |
| 8. Channel 1 select button |
| 9. Channel 2 select button |
| 10. 2.4”IPS display |
| 11. Speed shuttle key |
| Input Voltage : | AC 100-240V |
| Charge Current : | 0.1-12.0A * 2 |
| Discharge Current : | 0.1-3.0A * 2 |
| Max Charge Capacity : | 200W |
| Max Discharge Capacity： | 5W * 2 |
| Balancing Current : | 1A/cell * 2 |
| Balance Cells : | 6S * 2 |
| Display : | 2.4〃320×240 IPS LCD |
| Operating Temperature : | 0-40°C |
| Storage Temperature : | -20-60°C |
| Dimensions : | 120x108x70 mm |
| Weight : | 558g |
| USB Port： | 5V / 2A |
| Accessory : | AC input cable |
| Supported Batt. Type : | LiHv (1-6S) LiPo (1-6S) LiFe(1-6S) Lilon (1-6S) NiMH(1-16S) Cd(1-16S) Pb(1-12S) |
