CHECKER
Main Input port
7.0-35.0V @MAX 25A
Balance input
0.5V-5.0V Lixx 2-8S
Signal port input
<6.0V
Balance current
MAX 60mA @2-8S
Balance accuracy
<0.005V @ 4.2V
USB-A output
5.0V@1.0A firmware upgrade
USB-C output
5.0V-12.0V @MAX 20W
USB-C protocol
PD3.0 QC3.0 AFC SCP FCP
MEASURER
PWM
880-2200us @20-400Hz
PPM
880-2200us * 8CH @ 20-50Hz
SBUS
880-2200us * 16CH @ 20-100Hz
OUTPUT
PWM
1000-2000us @20-1000Hz
PPM
880-2200us * 8CH @ 20-50Hz
SBUS
880-2200us * 16CH @ 20-100Hz
GENERAL
Product size
68*50*15 mm
Product weight
50g
Packing size
76*60*30 mm
Packaging weight
100g
LCD
IPS 2.0″ LCD 320*240 Pixel
