CHARGE
Input voltage
7.0-35.0V @MAX 25A
Battery type
Lipo LiHV LiFe Lion LTO@1-8S
NiMh @1-20S Pb @1-12S
Balance current
1000mA @ 4.2V
Charging power
600W @MAX 20A
Discharging power
600W @MAX 20A Recycle mode
20W@3A Normal mode
USB
2.1A@5.0V or Upgrade
MEASURER
PWM
880-2200us @ 20-400Hz
PPM
880-2200us * 8CH @ 20-50Hz
SBUS
880-2200us * 16CH @ 20-100Hz
Voltage
1.0-5.0V @ 1-8S
Internal resistance
0.1 mR-99R @ 1-8S
ESC
600W @ 20A
OUTPUT
PWM
500-2500us @ 20-1000Hz
PPM
880-2200us * 8CH @ 20-50Hz
SBUS
880-2200us * 16CH @ 20-100Hz
Power supply
1.0-35.0V @1.0-20A mode:CC CV
Overcurrent response
<5ms
GENERAL
Product size
99*72*35mm
Product weight
180g
Packing size
125*81*41mm
Packaging weight
250g
LCD
IPS 2.4″ LCD 320*240
